you send what you have
Phone photos of each wall. A sketch with numbers on it. A tape reading for every room, taken twice, both diagonals included. Handwriting is fine; we have read worse.
Sheet A-000 / Cover / New London, CT
a drawing nobody measured twice is a guess.
Send the numbers you wrote on a stud bay in carpenter’s pencil. We return as-built plans and permit-ready CAD sets on 24 × 36 sheets. As-builts start at $340, billed per project by invoice.
Send the measurements Remote only · Daily 11am–6pm · (860) 448-8654
01 — Intake to issue
from stud-bay pencil marks to a sheet the building office reads once
we ask
One numbered list of missing dimensions. Usually seven items. Never more than twelve.
we draw
Layers named by convention: A-WALL-EXST dashed, A-WALL-NEW solid. Your engineer can open it without a phone call.
you check
Red-pen the PDF. One round is in the price. Each extra round is $58, flat.
we invoice once
One invoice per project, emailed with the final files. ACH, check, or card.
seven numbers that save a round of questions
- 01Wall thickness at one door opening (4½″ and 5½″ are different walls).
- 02Ceiling height in each room, measured at two corners.
- 03Window width, height, and sill height above the floor.
- 04Both diagonals of every room that isn’t obviously square.
- 05Direction the floor joists run, if you can see them.
- 06Location of the electrical panel and the water heater.
- 07The street and lot lines, if a deck or addition is involved.
02 — Sample sheets
three sheets, one inspector’s question each
Illustrative sheets drawn to show the format. Dimensions are typical, not from any client’s house.
“which wall is coming out?”
the kitchen that lost a wall
Demo drawn with a dashed accent line so the plan reviewer sees exactly one wall at stake, and the contractor sees exactly one wall to price.
- Includes
- Existing plan, demo plan, proposed plan
- Turnaround
- 3 business days from complete numbers
- Price
- $760 renovation plan set
“how far off the ground is it?”
the deck at 31½ inches
Thirty inches is where a guard becomes mandatory, so the sheet states the height in inches, calls out the guard, and shows footing depth below frost. Reviewers stop asking.
- Includes
- Framing plan, footing plan, ledger and stair details
- Turnaround
- 3 business days from complete numbers
- Price
- $485 deck permit packet
“can anyone get out of it?”
the basement at 7′-1″
Seven feet is the line for habitable space, and the sheet shows a ceiling number you measured, not one you hoped for. The egress window carries its clear-opening note.
- Includes
- Plan, egress detail, stair, code notes, 24 × 36 PDF
- Turnaround
- 5 business days from complete numbers
- Price
- $1,160 permit-ready CAD set
03 — Rate card, rev. 2026-10-24
rates, per project
“your quote is a number. it is the same number on the invoice.”
— Fieldstone Drafting, on every estimate we have ever written
One floor, up to 1,400 sq ft, drawn from your measurements and photos. Each added floor is $190. Delivered as DWG, DXF, and PDF within 2 business days of complete numbers.
Typical use / contractor estimate, insurance claim, resale Start with the $340 sheetExisting plan, demolition plan, and proposed plan for one project area, with room labels and a dimensioned layout your carpenter can frame from. Three business days.
Typical use / kitchens, baths, wall removals Order the $760 plan setFloor plans, four elevations, one building section, door and window schedule, title block, and code notes on 24 × 36 sheets. One markup round included. Five business days.
We do not stamp. If your town wants a licensed seal, we say so in the first reply, before you pay. Request the $1,160 setFraming plan, footing plan, ledger attachment and stair details, guard callouts, and a site sketch showing setbacks. Three business days.
Typical use / new decks, deck replacements, porches Get the $485 packetThe building office sent a list. We revise the sheets to answer it, one flat fee per round, back to you in one business day. Rush on any set: +$140 for 48-hour delivery.
Typical use / “please provide…” letters, second submissions Send us the comment letterBilling / one invoice per project · net 15 · ACH, check, or card · no retainer, no monthly seat
04 — Contact / intake
send what you have, even a photo of a stud
Spec / first-draft turnaround
48h
from complete measurements to the first draft of an as-built. “Complete” means every room has two diagonals.
Location
remote, from new london
31 Riverview Avenue Apt 2, New London, CT 06320. No site visits, no walk-ins; drawings arrive by email. Find riverview avenue on a map
Questions people ask before they write
We draw to the sheet and code-note format residential reviewers expect. We don’t stamp. If your project needs a licensed seal, the first reply says so, before any money moves.
We check every room’s diagonals. If two disagree by more than ½″, we flag the room and ask for a re-measure. Better us than the inspector.
Yes. Roughly half the projects start with a homeowner holding a tape measure. The checklist above is written for them.
